Recommendation requested for best budget Flat Top Grind TS blade

  • Advertise with us

« back to Power Tools, Hardware and Accessories forum

Forum topic by Douglas Bordner posted 03-23-2009 01:51 AM 2963 views 0 times favorited 10 replies Add to Favorites Watch
View Douglas Bordner's profile

Douglas Bordner

4012 posts in 3524 days


03-23-2009 01:51 AM

Topic tags/keywords: question ftg tablesaw

Hello LJs. I have been reading KnotScott’s great reviews of TS blades recently but I have a very specific request of the community. I recently attempted one of the Doug Stowe-type keyed miter boxes with my generally quite adequate Freud Fusion combination blade, but the ATB grind of this blade leaves a disappointing cut of the key slots.

That said, I know that there is a Forrest WWII out there with a FTG, but until I win the lottery, or it’s time to buy another go-to blade, I’d like your recommendation for a blade that is:
1). Cheap as this is for a very limited application. For this purpose a full kerf blade seems desireable.
2). Not so cheap that it will throw teeth, sound like an approaching tornado or shimmy like your sister Kate.

A buddy of mine gave me his stock (came with the saw) Delta ATBR and it was so evil sounding that I shut it down right away. To be fair it had not been stored adequately (thrown into a cat litter bucket filled with saved offcuts with no cover, at an angle etc). I truly don’t want to spend much here – just wanting a carbide toothed blade around 25 or so bucks. Any thoughts?

-- "Bordnerizing" perfectly good lumber for over a decade.


10 replies so far

View Scott Bryan's profile

Scott Bryan

27251 posts in 3282 days


#1 posted 03-23-2009 02:05 AM

Doug, what about using a dado blade? That should produce the type of kerf that you are wanting to cut.

-- Challenges are what make life interesting; overcoming them is what makes life meaningful- Joshua Marine

View TheCaver's profile

TheCaver

288 posts in 3300 days


#2 posted 03-23-2009 02:05 AM

Doug, if you send your blade (yes, even the Freud) to Forrest, they will grind it flat for you fairly cheap…..

Or maybe buying a cheaper blade and having them flat top it…...

BTW, they also can grind a custom bevel on teeth so that you can cut dovetails on the tablesaw, ie flatbottomed bevel cuts! :O

Scott, dado blades are angled in…..the overlap of the chippers give them a flat bottom…..Most of them anyway….

JC

-- Somewhere, something incredible is waiting to be known. -Carl Sagan

View knotscott's profile

knotscott

7208 posts in 2836 days


#3 posted 03-23-2009 02:15 AM

Hi Douglas – Glad to have provided some midnight reading for you.

A full kerf FTG blade is typically going to be available as a 24T ripper. Most blades beyond 24 teeth tend to have a grind that’s either TCG, ATB, or ATB/R, and none of those grinds leaves a perfectly flat bottom. Bosch does have a 60T FTG thin kerf on sale from Amazon for ~ $31 shipped…CB1060L. I haven’t tried that particular blade, but it should cut. Amazon also has a new line called Kempston that I haven’t tried…they look like Freud knock offs. They have a 10-inch 24T FTG ripper < $30 shipped, and they also have an 8-inch 24T FTG”:http://www.amazon.com/Kempston-99310-8-Inch-Industrial-Coating/dp/B0013KTUPC/ref=sr123?ie=UTF8&s=hi&qid=1237766948&sr=1-23 for < $27 shipped. Infinity does have a new box joint/flat bottom crosscut blade, but IIRC it’s around $60. There are likely others that I’ve overlooked or don’t know about. The next best thing to a flat top grind would be an ATB/R, and ATB with a low bevel angle of ~ 10°, or an ATB/R….lots of choices in those, but none will give the true flat bottom, and most will be over $25. Good luck!

-- Happiness is like wetting your pants...everyone can see it, but only you can feel the warmth....

View DocK16's profile

DocK16

1178 posts in 3547 days


#4 posted 03-23-2009 03:10 AM

No doubt the Freud fusion is not the blade for this task First thing I thought of was what Scott said about using a dado blade, but I think knotscott knows his blades, by the way no more references about my sister Kate.

-- Common sense is so rare anymore when you do see it, it looks like pure genius.

View John's profile

John

29 posts in 3244 days


#5 posted 03-23-2009 03:28 AM

View Damian Penney's profile

Damian Penney

1141 posts in 3452 days


#6 posted 03-23-2009 05:58 AM

I second Scott’s recommendation with regards using a dado blade, that’s what I used doing the Stowe boxes and it worked a treat.

-- I am always doing that which I can not do, in order that I may learn how to do it. - Pablo Picasso

View Douglas Bordner's profile

Douglas Bordner

4012 posts in 3524 days


#7 posted 03-23-2009 07:24 AM

Oddly, the only dado I have is a wobbler I bought with my first TS (a Craftsman) in 1991. All the dado work I’ve done with a plunge router or with the Incra fence. Might have to go with the Bosch and use thinner key stock or the Kempston etc.

-- "Bordnerizing" perfectly good lumber for over a decade.

View Scott Bryan's profile

Scott Bryan

27251 posts in 3282 days


#8 posted 03-23-2009 03:24 PM

Adrian's signature line- “THe 11th Commandment….. Thou Shalt Not Buy A Wobble Dado” says it well. I thought about this situation when I posted my comment. I am sure that I bought the same wobbler with my Craftsman saw as well. Needless to say it has been on the shelf since shortly after I bought it (once again I violated my personal philosophy of buying on the basis of quality rather than price which invariably has ended up costing me more in the long run). Once you go with a stacked set you never go back.

-- Challenges are what make life interesting; overcoming them is what makes life meaningful- Joshua Marine

View jockmike2's profile

jockmike2

10635 posts in 3707 days


#9 posted 03-23-2009 03:43 PM

Hey Doug, I’ve got a dado wobbler still in the package, never been used. I’ll pay the shipping if you want to try it…...snicker

-- (You just have to please the man in the Mirror) Mike from Michigan -

View Douglas Bordner's profile

Douglas Bordner

4012 posts in 3524 days


#10 posted 03-23-2009 06:47 PM

Thanks for bringing that up Scott (and Mike – you scamp!). That is where I first became of Adrian’s fine properties as a gentleman and an LJ. It also allows me to repost one of my favorite LJ “art” projects.

Beware Odysseus…nothing but ill can come from yielding to this temptation!

-- "Bordnerizing" perfectly good lumber for over a decade.
