Shop #1: Workshop: Clamps Storage

  • Advertise with us
Blog entry by Big Ben posted 01-03-2011 06:45 PM 6590 reads 1 time favorited 7 comments Add to Favorites Watch
no previous part Part 1 of Shop series Part 2: Drill Press Table and other shop upgrades »


With the start of the New Year, I figured I would really start things off on the right foot and get my shop cleaned and organized. I have an number of projects that I would like to complete but my woodworking ADD has gotten the best of me. So I figure I would start small and make some clamp racks, one of pipe clamps and one for bar clamps.
Pipe Clamp Rack

From Woodworking

From Woodworking

Bar Clamp Rack

From Woodworking

From Woodworking
I am a hobbyist so most of my clamps are Harbor Freight, they work fine but I would stay away from their aluminum bar clamps (http://www.harborfreight.com/36-inch-aluminum-bar-clamp-38184.html) I had one snap during a glue up.

From Woodworking

I have already started my drill press table for my next project, I will post the completed table soon (I hope).

From Woodworking



7 comments so far

View Eric_S's profile

Eric_S

1551 posts in 2660 days


#1 posted 01-03-2011 07:00 PM

Nice clamp racks! This is the only project I forgot to do this past week in my shop redo. Thanks for the post and inspiration to make my own.

I believe I have the same bar clamps, but mine came from Peachtree USA. The clamps have held fine, the thin metal handle though has bent on a few. I started using a piece of foam when gripping them to prevent all the blisters they gave me when tightening.

-- - Eric Noblesville, IN

View heller's profile

heller

12 posts in 2329 days


#2 posted 01-03-2011 07:35 PM

I had the same thing happen to me. One out of the HF aluminum bar clamps i have broke on a glue up in the same spot. Are the pipe clamps from Hf as well? If so how are they i have a project coming up that requires laminating a lot of 6/4 white oak and need some pipe clamps and was hoping Hf was going to come thru again.
Nice racks by the way.

View Big Ben's profile

Big Ben

87 posts in 2355 days


#3 posted 01-03-2011 08:08 PM

The pipe clamps are from HF as well. They work pretty good. I used them to glue up my bench which 4” thick Southern Yellow Pine with no issue.

From Woodworking

View heller's profile

heller

12 posts in 2329 days


#4 posted 01-03-2011 08:43 PM

Ok Great. Thanks

View jim C's profile

jim C

1467 posts in 2563 days


#5 posted 01-03-2011 10:31 PM

I don’t have that many….....yet, but I took those closet shelf brackets and put a 1×6” board in them. They hold the bar clamps really well.

-- When I was a boy, I was told "anyone can be President", now I'm beginning to believe it!

View PurpLev's profile

PurpLev

8523 posts in 3113 days


#6 posted 01-03-2011 10:41 PM

nice rack! (lol)

the only thing I’d be concerned about especially with PIPE clamps which are ubber heavy is the height they are hung at. I would not hang clamps anywhere above head level, see my reason:
http://lumberjocks.com/topics/7861

Be safe

-- ㊍ When in doubt - There is no doubt - Go the safer route.

View Cory's profile

Cory

758 posts in 2884 days


#7 posted 01-04-2011 08:08 PM

Nice start on your clamp racks. I have several parallel and pipe clamps all stored together on one rack. I don’t have a lot of wall space, so I chose to come out away from the wall. It works really well, but I’ll probably build a rolling clamp rack to save myself from having to make multiple trips with heavy clamps. Here are my racks:

quick grips:

Parallel and pipe clamps:

Updated location and clamps

-- The secret to getting ahead is getting started.
